Customized Hospital Wall Panel Quick Install Modular Operating Theatre Room Wall Panel Modular Solution
|
Product Name:
|
Operating Room Wall Panel
|
Suitable:
|
Hospital Industry
|
|
Dimensions:
|
Customized
|
Cornering Method:
|
R300 Steel Arc Or Steel Octagonal Bevel
|
|
Materials For Optional 1:
|
First-class Environmentally Friendly Electrolytic Steel Plates
|
Materials For Optional 2:
|
Stainless Steel Plates
|
|
Interior Of Wall Panel:
|
High Strength Fire-resistant Gypsum Board Or Calcium Silicate Board
|
Surface Finish:
|
Antibacterial And Easy-to-clean
|
Modular Operation Room Panel
The ceilings are available in square or rectangular shapes in order to suit any room layout and answer specific requirements to create a clean zone around the patient, medical staff and medical devices.
Aerobiologically, the things that generate most airborne contamination in an operating theatre are the staff. The most common unit of contamination (colony forming unit – “cfu”) is a microcolony on an airborne skin scale. That microcolony will contain between 1and 1,000 bacteria. (Microbial numbers are a critical factor in initiation of infection).
A significant purpose of operating theatre ventilation is to prevent airborne bacteria from settling-out in « the wound ».
Our laminar flow ceilings are mainly used with our Clinic air Air Handling Unit, but can be also adapted to any type of products from a different brand. This system is dedicated to operating theatres in order to meet ISO 5 standard (complying with EN ISO 14644-1 ) as well as to pharmaceutical industry. It helps fight cross contamination and hospital borne infections.
CURRENT MAIN REQUIREMENTS FOR LTF CEILING SYSTEMS
|
Cleanliness
|
Maximum average concentration of bacteria by sedimentation method (plankton method)
|
Air cleanliness level
|
Reference surgery
|
||
|
Operation Area
|
Around area
|
Reference surgery
|
Around area
|
||
|
I
|
0. 2cfu/30min
φ90 (5cfu/m³) |
0.4 cfu /30min
φ90 (10cfu/m³) |
5
|
6
|
Prosthesis implants, certain large organ transplants, surgical site infections can directly endanger life and quality of life and
other operations |
|
II
|
0. 75cfu/30min
φ90 (25cfu/m³) |
1. 5cfu/30min
φ90 (50cfu/m³) |
6
|
7
|
Major surgery involving deep tissues and major organs of life
|
|
III
|
2. 0cfu/30min
φ90 (75cfu/m³) |
4. 0cfu/30min
φ90 (150cfu/m³) |
7
|
8
|
Other surgical procedures
|
|
IV
|
6. 0cfu/30min φ90
|
8.5
|
Infection and severe contamination surgery
|
||
Operation Room Classification
(1) Class I operating room: the sterile clean operating room, which mainly accepts operations such as brain, heart, and organ transplants.
(2) Class II operating room: the sterile operating room, which mainly accepts aseptic operations such as splenectomy, open reduction of closed fractures, intraocular surgery, and thyroidectomy.
(3) Class III operating room: that is, the operating room with bacteria, which accepts operations on stomach, gallbladder, liver, appendix, kidney, lung and other parts.
(4) Category IV operating room: the infection operating room, which mainly accepts surgery for appendix perforation, peritonitis, tuberculous abscess, abscess incision and drainage.
(5) Category V operating room: the special infection operating room, which mainly accepts the operation of Pseudomonas aeruginosa, gangrene bacillus, tetanus and other infections. According to different specialties, the operating rooms can be divided into general surgery, orthopedics, obstetrics and gynecology, brain surgery, cardiothoracic surgery, urology, burns, and ENT surgery.
Cleanliness
The cleanliness grade of hospital clean room is generally divided into class100, class1000, class10000, class100000 etc.
